Magnetostrictive Level Sensor
Model
RS485
Anticorrosion magnetostrictive linear level transducer,Flexible magnetostrictive linear level transducer,Magnetostrictive linear level transducer, (hard tube) (oil and chemical).Magnetostrictive linear level transducer kami merupakan contactless liquid level sensor yang dirancang untuk pengukuran absolute level cairan secara akurat. Alat ini dapat memantau actual fluid level dan temperature secara bersamaan. Dengan menggunakan komunikasi yang andal untuk monitoring dan programming melalui EIA-RS485, data dapat dikirimkan secara remote. Desain dan durability sensor menjadikannya ideal untuk pengukuran fluid level pada petroleum. Transducer menyediakan analog output berupa voltage dan current serta digital output menggunakan Modbus. Dengan memanfaatkan integral digital temperature sensor yang terdapat pada probe, fluid temperature dapat diukur bersamaan dengan level.
INFORMASI PRODUK
Deskripsi Produk
| Measured Position | Modbus—1~3 position or 1~5 temperature points Analog—1~2 position |
| Operating Voltage | +24VDC ±10% ; ±15VDC±10% |
| Outputs | 0~5VDC; 0~10VDC; -5~+5VDC; -10~+10VDC; 4~20mADC; ModBus; Hart |
| Range | Rigid structure: 50~5000mm Flexible structure: 4000~20000mm |
| Load Characteristics | Current output:Load Resistance 600?(Max.) Voltage output:Load current 2mA(Max.) |
| Operating Current | <70mA |
| Operating Temperature | -40~+85 °C |
| Storage Temperature | -40~+100 °C |
| Non-linearity | <±0.01% F.S.or 1mm max. |
| Repeatability | <±0.002% F.S. |
| Resolution | 16bit D/A ,0.1mm |
| Hysteresis | <±0.002% F.S. |
| Temperature Coefficient | <±0.007%F.S./°C |
| Zero Range | 100%F.S. |
| Full-scale Range | 100%F.S. |
| Update Time | Depends on range, but less than 20ms |
| Probe Material | A.0Cr18Ni9(304) B.316SS |
| Housing Material | A.0Cr18Ni9(304) |
| Mounting | A. Threaded connection B. Threaded flange |
| Cable | Integral cable, mating connector, integral connector |
| Sealing | Housing: IP65, Probe: IP68 |
| Explosion Proof | Exd IIBT5, Exia IICT6 |
| Note: The F.S. is short for Full Scale. |
